Brand Name : SINOMATIC
Model Number : DKC500DC
Certification : CE/ ISO
Place of Origin : China
MOQ : Sample order accepted
Price : negotiable
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram, Alipay, Paypal, Credit card
Supply Ability : 10,000 pcs per month
Delivery Time : 5-10 working days after payment received
Packaging Details : Carton/Plywood box/Pallet
Package : Carton box
Remote Control Range : >30 meters
Loading Weight : 500/800 KG
Max Gate Length : 12m
Supply Voltage : 220V/50Hz; 110V/60Hz
Alarm : available
Motor : DC motor
Working Duty : S2, 20min
Material : ABS, Aluminum Alloy
Opening Speed : 13m/min, 18m/min,
Prouduct description
DKC500DC/DKC800DC SLIDING GATE OPENER Designed for residential sliding gate weights up to 500/800 Kg and operating distance up to 12 meters.
1. Compact structure, novel appearance, easy installation.
2. Built-in control board, optional for backup battery and solar charger.
3. MCU is supplied to control the gate opener.
4. Keypad / single button interface.
5. Alarm lamp, Photo beam & safety beam interface.
6. User can select auto-close function.
7. Magnetic limit switch, soft start & slow stop function.
8. Manual key release design for emergency purposes.
9. Automatic stop when hitting obstacle during opening, auto-reverse when hitting obstacle during closing.
10. Solar System compatible
Product specifications
Unit Model | DKC500DC | DKC800DC |
Power Supply | 220V,50Hz;110V,60Hz | |
Max. Gate Weight | 500KG | 800KG |
Motor Power | DC24V,150W | DC24V,170W |
Gate Moving Speed | 11-13 m/min | 16-18 m/min |
Limit Switch | Magnetic limit switch/spring | |
Recording of up Remotes | 40 | |
Decoding / Frequency | Rolling code / 433.92MHz | |
Work Duty | S2 20min | |
Noise | ≤58dB | |
Work Temperature | -20°C~70°C | |
Gross Weight | 10 KG |
Optional parts
Maintenance
The gate should be checked every month to make sure it operates normally.
For the sake of safety, each gate is suggested to be equipped with infrared protector, and regular inspection is required.
Before installation and operation of the gate opener, please read all instructions carefully. Our company keep the right to change the instruction without prior notice.
FOR MORE DETAILS, PLEASE CLICK THE BELOW LINK TO DOWNLOAD THE USER MANUAL.
DKC500DC, DKC800DC User Manual.pdf
![]() |
